Processing format: 1500mm*3000mm

Max running speed: 50m/min

Maximum acceleration: 0.3G

X/Y positioning accuracy X/Y:0.05mm/m

X/Y repeated positioning precision X/Y: 0.05mm

Working voltage: 50HZ 220V

Laser power: 300W/500W

Total power of the whole set of equipment: <15KVA

The operation of the machine tool temperature 0 degrees C-40 degrees: C

Machine operating humidity: <90%

Weight of the whole machine: 2500kg

Appearance size: 3600*2100*1500mm

Transmission mode: precision ball screw rotation

1, high rigidity machine, CNC high temperature furnace annealing process exclusive standard annealing treatment can ensure the precision of the machine tool long time constant;

2, imported original packaging fiber laser, beam quality is good, stable performance, no reflection lens, no need to adjust the light path, basic maintenance free, service life of up to more than 100 thousand hours;

3, fiber laser light conversion efficiency is high, the conversion efficiency of 30%, can greatly save the work of power consumption, running cost is very low

4, the use of imported drive and servo motor, high precision, high speed;

5, can design a variety of graphics or text immediately cutting, the operation is simple, flexible and convenient.

6, cutting edge quality smooth and smooth, small deformation;

7, low energy consumption, energy saving and environmental protection, low power consumption, the power consumption is the same power 1/3-1/5 power consumption of YAG, the cutting speed is more than three times YAG;

8, laser produced no need to occur gas, can be used to cut the sheet of air;

9, cutting speed, operating cost is very low, fast return on investment;

This product has the characteristics of high speed, high precision, high efficiency, low consumption, long service life, maintenance free, has become the necessary equipment for many businesses.
