- Place of Origin: jinan
- Brand Name: naike
- Model Number: 005
Performance parameter:
Performance parameter description
X, Y axis stroke 1300mmX2500mm
Z axis stroke 200mm
Running speed 26m/min
Processing speed 16m/min
Repeated positioning accuracy of 0.05mm
Engraving instructions G code * u00 * plt.eng
Spindle speed 0~1600r/min, 0~24000r/min
Working mode servo motor drive
Computer control system for optional control system
Name configuration
The back type engraving machine
Bed side rail welding
Longmen thick
Spindle 5.5KW air-cooled spindle
Motor Torpedo servo motor
Operating system handle Weihong system /DSP
Guide rail three axle imported square rail
Rack drive X, Y shaft rack drive, Z axis screw drive
Frequency converter 5.5KW
Mesa vacuum adsorption Mesa
Vacuum pump 5.5KW
Vacuum cleaner 3.0KW dual cylinder
Wentai, carving and engraving software
